LR5000 Home Energy System
|
|
|
|
Description |
|
|
Ø Longer life cycle: Battery pack 3000 cycles, 5x lead acid battery; Ø Lighter weight: Higher energy density, 0.4x lead acid battery; Ø High rate discharge: 2x rate than lead acid battery and remain 95% capacity; Ø Wide temperature range: -20~50℃; Ø Superior safety: Lithium Iron Phosphate chemistry eliminates the risk of explosion or fire due to high temperature shock, overcharging, or short circuit conditions; Ø Home energy storage, industrial and commercial energy storage. |
|
|
Product Specification |
|
|
Module Type |
LR5000 |
|
Total Energy |
5kWh |
|
Nominal Voltage |
51.2 V |
|
Usable Energy(DC) |
4.6kWh |
|
Nominal Capacity |
50A |
|
Nominal Dis-/Charge Power |
3kW |
|
Weight |
65kg |
|
Dimension(mm) |
453×433×177mm |
|
Safety |
CE,UN38.3,IEC62619,IEC63056,IEC62477 |
|
Max.DOD |
90% |
|
Operating Condition |
Indoor or outdoor |
|
Humidity |
4~100% (No condensed water) |
|
Pollution Degree |
3 |
|
IP Rating |
IP 20 |
|
Max. of Parallels |
16 |
|
Warranty |
10 years |
|
Life Span |
>15 years |
|
Battery Protection |
Over-current/Over-voltage/Short-circuit/Under-voltage |
